Cladding Power Stripper (CPS)


High Power Handling
Minimal Signal Loss
Application High Power Fiber Laser
High Power Fiber Amplifier
Download
관심제품등록

Product Info

Product Name: High Power Cladding Power Stripper

The Cladding Power Stripper (CPS) is designed for efficiently stripping off residual cladding power, ASE and escaped core modes of double cladding fiber while preserving minimal degradation to signal power and beam quality.



Key Feature

-High Power Handling

-Minimal Signal Loss



Applications

-High Power Fiber Laser

-High Power Fiber Amplifier



Specifications

Parameter

Unit

Value

Operating Wavelength Range

nm

800 - 2000

Min. Stripping Efficiency

%

98

Signal Insertion Loss

dB

0.3

Fiber Type for Input and Output



10/125 DCF or 20/130DCF or 30/250 DCF

Max. Stripped Power

W

20

50

200

800

Package Dimensions

mm

P2

P5

P7

P8

Operating Temperature

 -5 to +60

Storage Temperature

 -40 to +85
