Beam'R2 – XY Scanning Slit Beam Profiler System 190 to 1150 nm, Silicon detector 650 to 1800 nm, InGaAs detector 1000 to 2300 or 2500 nm, InGaAs (extended) detector Beam diameters 5 µm to 4 mm, to 2 µm in Knife Edge mode Port-powered USB 2.0; flexible 3 m cable, no power brick 0.1 µm sampling and resolution Linear & log X-Y profiles, centroid Profile zoom & slit width compensation Economical and accurate M² option – beam propagation analysis, divergence, focus |
|
| Application |
Laser printing & marking Medical lasers Diode laser systems Fiber optic telcom assembly focusing – LensPlate2™ option for re-imaging waveguides and fiber ends Development, production, field service CW; Pulsed lasers, Φ µm ≥ [500/(PRR in kHz)] M² measurement with available M2DU stage |
|
| Download | ||
Product Info
Single Plane XY Scanning Slit, 190 – 2500* nm
Port-powered USB 2.0
| Specification | Detail |
|---|---|
| Wavelength | Si detector: 190 to 1150 nm InGaAs detector: 650 to 1800 nm Si + InGaAs detectors: 190 to 1800 nm Si + InGaAs (extended) detectors: 190 to 2300 or 2500 nm |
| Scanned Beam Diameters | Si detector: 5 µm to 4 mm‚ to 2 µm in Knife-Edge mode InGaAs detector: 10 µm to 3 mm‚ to 2 µm in Knife-Edge mode InGaAs (extended) detector: 10 µm to 2 mm‚ to 2 µm in Knife-Edge mode |
| Beam Waist Diameter Measurement | Second moment (4s) diameter to ISO 11146; Fitted Gaussian & TopHat 1/e² (13.5%) width User selectable % of peak Knife-Edge mode for very small beam |
| Measured Sources | CW; Pulsed lasers‚ Φ µm ≥ [500/(PRR in kHz)] |
| Resolution Accuracy | 0.1 µm or 0.05% of scan range ± < 2% ± = 0.5 µm |
| Maximum Power & Irradiance | 1 W Total & 0.5 mW/µm² |
| Gain Range | 1‚000:1 Switched; 4‚096:1 ADC range |
| Displayed Graphics | X-Y Position & Profiles‚ Zoom x1 to x16 |
| Update Rate | ~5 Hz |
| Pass/Fail Display | On-screen selectable Pass/Fail colors. Ideal for QA & Production. |
| Averaging | User selectable running average (1 to 8 samples) |
| Statistics | Min.‚ Max.‚ Mean‚ Standard Deviation Log data over extended periods |
| XY Profile & Centroid | Beam Wander display and logging |
| Minimum PC Requirements | Windows, 2 GB RAM, USB 2.0/3.0 port |
