0.02-5m Laser Range Finder Sensor -. High accuracy -. High measuring-frequency -. Friendly interfaces, user-friendly -. Waterproof IP67 -. Compactness |
|
| Application |
-. Smart home, Proximity senor -. Displacement sensor for elevator, lift and conveyor -. Rear anti-collision alarm -. Warehouse automatic loading/unload-ing system, Industry 4.0, Industrial automation -. LRF |
|
| Download |
|
|
Product Info
Application：
Smart home, Proximity senor
Displacement sensor for elevator, lift and conveyor
Rear anti-collision alarm
Warehouse automatic loading/unload-ing system, Industry 4.0, Industrial automation
Features：
High accuracy
High measuring-frequency
Friendly interfaces, user-friendly
Waterproof IP67
Compactness
- Accuracy: ±2mm
- Repeatable accuracy: ±2mm
- Resolution: 0.5nm
- Frequency: 1-1000Hz
- Range: White subject indoor:0.02-5m
- Wavelength: 780nm
- Laser Class: Class1
- Beam angle: <1 (Full-width)mrad
- Baud: 9600bps
- Data interface: RS232/RS485/0-5V/TTL
- Operating temperature: -30～+60℃
- Storage temperature: -40～+70℃
- Water and dust proof: IP65
- Can material: Al alloy (black)
- Dimensions: 42.25*22*22mm
- Installation dimensions: 29*2-M2.5*H5; L12*2-M2.5*H5mm
- Weight: 46.5g
- Power consumption: <2W
- Voltage: DC6-24V
